A solar panel spec sheet provides valuable information about the operating parameters of a panel and can help designers, engineers, and installers determine how to configure a solar PV system.
The panel spec sheet will tell you about the panel’s electrical power production, including its efficiency and how it operates with changing temperatures, as well as mechanical information like the dimensions and wind loads. This information is required to get an accurate performance simulation.
How to read a solar panel spec sheet
If your first solar spec data sheet looks like a foreign language, don’t be concerned. There’s a lot of unique jargon that goes into it, but we’re here to help you out. Our research engineer, Andrew Gong, will walk you through the terms to know and what you should expect.
What is Pmax rating?
The first value people should pay attention to is the maximum power point, commonly abbreviated to Pmax or MPP rating.
“Maximum power point is a combination of voltage and current,” Gong explains. “It’s the combination of volts and amps that creates the highest wattage.
“If you lower the current and increase the voltage, you move away from the maximum power point,” he continues.
Typically, solar panels are rated between 250 and 400 watts. Higher wattage generally means a system will be more efficient and require fewer modules.
Understanding voltage in solar panel specs
Voltage is also an important consideration.
If, for example, a designer decided on 12 panels in a string, it’s important to make sure the voltage doesn’t exceed certain thresholds.
“You want to size the system so it doesn’t exceed 600 volts per string,” Gong explains. Above that, the panel won’t operate as well.
Solar panel efficiency
Installers, engineers, and designers should consider efficiency ratings. On average, solar panel efficiency ranges from 15% to 20%, with some panels as high as 23%. As cell technology improves, so do efficiency ratings.
A spec sheet also provides information about the assumptions used to create a panel’s operating parameters.
For example, SunPower’s spec sheet provides a range of temperatures, from -40 C degrees F to 85 degrees C. That’s listed under Operating Condition and Mechanical Data.
“In colder temperatures, panels operate a bit better,” Gong says.
In extreme weather, consider temperature ranges
How does weather affect solar panel efficiency? The temperature ranges of modules generally are between -20 degrees C to +85 degrees C in the U.S. In areas with more extreme temperatures — such as Alaska — installers and designers should be aware of panels’ temperature ranges.
Another value is the operating cell temperature, says Gong. “Some panels run hotter than others. This value tells you how modules respond to various levels of sunlight.”
It’s also important to understand current in panels. Under the heading of electrical data, a spec sheet provides a rated current.
“If you exceed the current, you destroy the panel,” says Gong. “Maximum current depends on the panel and how many parallel strings in the system.”
Ratings that are important in areas with high winds
In areas of extreme weather — those susceptible to high winds or snow — installers should pay attention to the mechanical or static load ratings.
The front side rating focuses on the snow load, and the back side rating is about the wind load.
The load figures appear in Pascals, a unit of pressure. Higher numbers mean the panel is stronger.
What your solar specifications sheet should include
Material characteristics
A specs sheet should have information on the material characteristics, including vital information about the size and dimensions of the solar panels.
Electrical specifications
The electrical specifications are where a lot of the technical terms and metrics begin to show up. It will include data on important specs such as Pmax and temperature testing. Below is a list of some important electrical specifications within solar panel specification sheets.
Nominal Operating Cell Temperature (NOCT)
The expected operating temperature of a solar cell is important for determining the output it will provide. The Nominal Operating Cell Temperature (NOCT) is the temperature reached by a solar panel under four standard environmental conditions:
- Sunlight hitting the solar panel = 800 watts/sq meter
- Wind velocity = 1 m/s
- Air temperature = 20°C (68°F)
- Panel angle = 45° from horizon
NOCT has a major impact on solar panel performance, and must be factored into any solar system planning and optimization.
Temperature coefficient (%/ °C)
When silicon in PV cells heats up, they become less efficient. A solar panel’s temperature coefficient shows the relationship between PV output and the temperature of the solar panel, and is represented as the overall percentage decrease in power over for each degree of temperature rise.
Maximum Power Point (MPP)
The Maximum Power Point represents when a solar panel has maximum power output. MPP, changes slightly with temperature and sunlight intensity.
Maximum Power Point Voltage (Vmp)
This is the available voltage of a connected panel operating at max capacity under standard testing conditions. Most manufacturers rate their panels around 70-80% of the Open Circuit Voltage (VOC).
Maximum Power Point Current (Imp)
Maximum Power Point Current (Imp) is the current (amperage) a solar panel produces at maximum power output. It’s the current you want to see when the panel is hooked up to a charge controller under standard test conditions. Imp varies with the intensity of sunlight hitting the panel.
Open Circuit Voltage (Voc)
Open Circuit Voltage (Voc) is the maximum voltage a solar panel can produce without a load. Voc is measured at the unconnected terminals of a solar panel to check or test the panel during installation.
Short Circuit Current (Isc)
Short Circuit Current (Isc) is a measurement of the current produced when the positive and negative terminals of a solar panel are connected to each other. Isc shows the highest current a solar panel can deliver without damaging itself, and is used to determine how many amps a panel can safely handle when connected to a load.
Power tolerance
Power tolerance is a measurement of how much power a solar panel can produce below or beyond its rated capacity. For example, a 100 watt panel with a -4%/+4% power tolerance could produce 96 to 106 watts in real-life conditions.
Module efficiency (%)
A solar panel’s module efficiency measures how much sunlight hitting the panel is actually converted to electricity. The higher the module efficiency, the fewer panels it takes to get the job done.
Certifications
Quality solar panels undergo rigorous testing under various environmental stressors to ensure quality and safety. Solar panel certifications are printed on a solar panel’s spec sheet. Common solar panel testing and certification standards are established by the International Electrotechnical Commission (IEC) and Underwriters Laboratories (UL).
Warranties can vary
Solar spec sheets also mention warranties. Most have 25-year warranties, according to Gong. Some manufacturers offer a 90% warranty for 10 years, and decrease that amount as the panels age. Premium panels have better warranties.
